January 6, 2026 · 3 min read

Aero Wheels — Are Deep-Section Rims Worth It?

Deep-section rims are the most visible difference between a showroom bike and a race machine. They look fast — but are they really? And should an amateur who isn't racing for seconds invest in them?

How do aero wheels work?

Air resistance rises with the square of speed — above 30 km/h it's the dominant resistance on a bike. Aero wheels (rims 40–80 mm deep) have a profile similar to an aeroplane wing — air flows around them with less resistance than around flat, box-section rims (20–25 mm).

The deeper the rim, the bigger the aero benefit — but also the more it's affected by crosswinds, and the heavier it is.

How much do you actually gain?

*At 35 km/h, zero crosswind, vs typical aluminium box-section wheels. Data from various manufacturers' wind-tunnel tests — figures are approximate.

At 25 km/h the gain is minimal (2–5 W). Aero wheels start working for you once you regularly ride above 30 km/h.

The downsides of deep rims

• Crosswind — a 60 mm+ rim catches the wind like a sail. In gusts above 40 km/h, riding becomes unpleasant and dangerous.
• Weight — 50 mm aero wheels weigh 1,500–1,800 g (a pair). Light shallow wheels: 1,300–1,500 g. On climbs, weight matters more than aero.
• Price — decent carbon aero wheels start at around €700, top-end ones run €1,850–3,500 a pair.
• Braking — carbon rims with rim brakes stop worse in the wet than aluminium ones. With disc brakes, this problem doesn't exist.

When do aero wheels make sense?

• Time trials / triathlon — a steady high speed, no peloton, aero is the dominant factor.
• Flat routes, >30 km/h — regular fast group rides, flatland sportives.
• Your bike is already well set up — aero wheels are the icing on the cake, not the foundation.

When is it better to stick with shallow rims?

• Lots of climbing — lighter wheels gain you more than aero does.
• Strong crosswinds where you ride.
• A budget under €700 — for that money, better to invest in a good bike fit and in training.

The compromise: 40–50 mm

40–50 mm rims are the sweet spot: a noticeable aero gain, moderate wind sensitivity, sensible weight. Most manufacturers (Hunt, Scribe, DT Swiss) offer wheels in this range for €700–1,150 that last for years.

Summary

Aero wheels give a real gain — but only above 30 km/h on the flat. For most amateurs, 40–50 mm is the optimal compromise. Before you spend €1,150 on wheels, make sure your FTP is up to date and your position is right — free watts from training beat expensive watts from carbon.
